Delta Armory M4 / AR15 M-LOK 10" CHARLIE – Black

Delta Armory AR15 M-LOK CHARLIE

Delta Armory AR15 M-LOK CHARLIE offers a balanced combination of affordability, performance, and reliability. Inside, you'll find a reinforced Version 2 gearbox designed to handle springs around M120 over the long term, along with proven internal components such as an SHS piston with full steel teeth, metal gears, and 7 mm plain bearings. Accuracy is ensured by the 6.03 mm precision inner barrel and a rotary hop-up chamber that maintains its setting even during burst fire. One of the key advantages is the QRS Gen2 quick spring change system, allowing spring replacement within minutes without disassembling the rifle. The durable ABS polymer receiver keeps weight low while maintaining strength and is complemented by a polymer M-LOK handguard. Also worth mentioning are the modern CNC trigger and adjustable stock with enough room for larger Crane-type batteries Crane. The Charlie series uses traditional mechanical trigger contacts. If you plan to use powerful 11.1 V batteries over the long term, we recommend installing an ETU control unit such as the JeffTron Leviathan V2 / Scylla V2 or Perun Hybrid V2, or at least a MOSFET.This professional product description was prepared by the expert team at ANAREUS.cz. All rights to this unique content are reserved for anareus.cz.

Key Features of the Delta Armory CHARLIE Rifle

Technical Specifications

• Weapon Type: AEG (Electric)
• Length: 715–795 mm
• Inner Barrel Length: 280 mm
• Weight: 2100 g
• Velocity: Approx. 115 m/s (with 0.20 g BB)
• Gearbox: V2 (TM Standard)
• Hop-Up: Yes, Adjustable (Rotary)
• Fire Modes: Semi, Full Auto
• Bearings: 7 mm Sleeve Bearings
• Piston: SHS Reinforced (14 Steel Teeth)
• Barrel Thread: 14 mm CCW
• Body Material: ABS Polymer
• Handguard: M-LOK 10" (Polymer)
• Variant: CHARLIE
• Quick Spring Change: Yes (QRS Gen2)
• Motor: Standard Long-Type
• Magazine Capacity: 120 BBs
• Recommended Battery: Li-pol / Li-Ion 7.4 V (Not Included)
• Connector Type: Small Tamiya

Package Contents

• Delta Armory M4 / AR15 M-LOK 10" CHARLIE AEG Rifle
• DMAG Mid-Cap Magazine (120 BBs)
• RIS Rails for M-LOK Handguard (3 pcs)

Warning

• We recommend using a 7.4 V Li-Pol battery for optimal performance and service life.
• Regularly clean the barrel and maintain the hop-up unit for maximum longevity.
• For airsoft use only. Always wear eye protection.
• When using an 11.1 V battery, a MOSFET or ETU unit is required.
• Some manufacturers' springs are significantly overrated (for example, an SHS M120 spring can perform similarly to an M130–140 spring) and may exceed the gearbox's rated durability. We recommend choosing quality M120 springs to avoid damage caused by springs that do not match their stated rating.
• When installing a progressive spring, ensure the end with tighter coils is positioned on the spring guide facing outward from the gearbox.
• Never store the rifle with the battery connected.
