LGS NVG PVS-14 MACHOS CNC adapter - Black

MACHOS CNC Adapter for PVS-14

Looking for a quality CNC adapter that allows you to mount your NVG device PVS-14 onto M.A.C.H.O.S. v2020 or FAST v2020 bases by LGS? Want an adapter that replaces the left or right arm and provides stable, precise and ergonomic mounting? Need your NVG to sit closer to the head to reduce neck strain? Then this CNC PVS-14 adapter is the ideal choice. The arm offers smooth folding with adjustable tension via the front M5 screw, allowing you to fine-tune the resistance exactly to your preference. It is compatible not only with PVS-14 featuring a 37 mm neck diameter, but also with devices of similar dimensions and a smaller control knob (<22 mm). The adapter aligns the optical axis with the opposite arm, making it compatible with devices such as Sionyx Aurora, FLIR Breach, NYX-14 and more. Thanks to its CNC-machined aluminum construction, the part is lightweight, rigid and completely free of play. The package contains a single arm, usable on both left and right sides. With two adapters, you can mount two monocular NVG devices simultaneously in a bino configuration.

Example of the PVS-14 adapter installed in a M.A.C.H.O.S. mounting base

Key Features

• Universal left/right arm:
  Single part usable on both sides.


• Compatibility with PVS-14:
  For devices with a 37 mm neck diameter and a power knob smaller than 22 mm.


• Adjustable folding tension:
  Fine adjustment via the front M5 screw.


• Ergonomic close-to-head placement:
  Allows the optic to sit closer to the helmet, reducing neck fatigue.


• CNC 6061 aluminum:
  Lightweight, rigid construction with zero play.


• Full compatibility with M.A.C.H.O.S. v2020 / FAST v2020:
  Direct connection to the central mounting section (base not included).

Technical Specifications

• Material: CNC-machined 6061 aluminum
• Dimensions: 70 × 35 × 70 mm
• Compatibility: PVS-14

Package Contents

• CNC PVS-14 adapter for LGS MACHOS mounting base
