EPeS Snow Wolf M24 Sniper Upgrade Cylinder Set

EPeS Sniper Air System Upgrade Set for Snow Wolf M24

Looking for a way to get the maximum accuracy, range, and shot silence out of your bolt-action sniper? Want to buy a ready-to-use, hand-tuned set made specifically for your rifle? Need an easy upgrade that requires only a drop-in cylinder replacement? The EPeS Sniper Air System Upgrade Set delivers a complete package of carefully designed and pre-installed components that significantly improve rifle performance. It includes a tight stainless cylinder with sealed head and Sorbopad, CNC spring guide with bearing and POM sleeve, a high-power M150 spring, and a CNC Variable Mass Piston (VMP) with stainless and dural weights. With adjustable piston weight, you’ll achieve quiet shots, higher energy, and stable groupings with heavier BBs (Joule creep effect). The spring guide with bearing and anti-vibration sleeve reduces vibration and noise, while the Sorbopad protects internal parts and extends their lifespan. Each set is individually tested at EPeS for sealing, smooth operation, and noise, ensuring you receive a fully assembled, ready-to-use cylinder. Note: adjusting piston weights is not plug-and-play – proper knowledge of bolt-action mechanics is required.

Recommended Piston Weight Tuning Process

1. Select your target BB weight (e.g., 0.43 g, 0.49 g).
2. Test weight combinations from lightest to heaviest and record the total piston weight.
3. Fire 3–5 shots per configuration, record average Joules, and monitor shot noise.
4. Choose the setup that delivers the highest consistency with acceptable sound levels.
5. Verify results in the field with hop-up adjusted.

Key Features

• Complete CNC set:
  Stainless cylinder, CNC spring guide with bearing, VMP piston, CNC cylinder head with Sorbopad, guiding components.


• M150 spring:
  Optimized stiffness for higher performance and consistency.


• Variable Mass Piston (VMP):
  Adjustable stainless + dural weights for fine-tuning power and noise.


• Spring guide with bearing and POM sleeve:
  Reduces vibration and spring noise.


• Sorbopad on cylinder head:
  Absorbs piston impact, lowers noise, and protects internal parts.


• Tested by EPeS:
  Checked for sealing, piston fit, smoothness, noise, and performance before shipping.

Technical Specifications & Compatibility

• Compatibility: Snow Wolf M24
• Cylinder: CNC stainless steel
• Piston: CNC VMP with stainless sleeves + dural weights (blue finish)
• Spring guide: CNC with bearing and POM anti-vibration sleeve
• Spring: M150 (AirsoftPro or equivalent)
• Recommended BB weight: 0.43–0.48 g depending on piston load
• Performance (max piston load in EPeS Custom Sniper): 3.5 J (0.48 g)

Package Includes

• CNC stainless cylinder
• CNC cylinder head with Sorbopad
• CNC VMP piston
• 4× stainless piston weights (pre-installed)
• 4× dural piston weights (blue)
• CNC spring guide with bearing and POM sleeve
• M150 spring
• Assembly accessories and basic installation guide

Warning

• This set requires advanced technical knowledge and experience with bolt-action airsoft rifle assembly.
• Performance and sound depend heavily on tuning (barrel, hop-up, sealing, fitting of parts).
• For minimal noise, use a quality suppressor and precisely fitted piston rings.
• Improper installation may damage rifle or components; professional assembly is recommended.
• All sets are hand-tested at EPeS before shipping.
